How Do You Select MPP Foam Thickness for EV Battery Packs?

Choosing MPP foam thickness simply by matching the nominal battery gap can create excessive cell pressure during assembly or too little pressure later in battery life.

Select MPP foam thickness from the complete compression window, not from the nominal gap alone. Cell spacing, dimensional tolerance, beginning-of-life compression, end-of-life swelling and the required pressure range should all be considered before the pad thickness is frozen.

Why Is the Nominal Cell Gap Not Enough?

A pad sized only for nominal geometry can become over-compressed in the smallest gap and under-compressed in the largest gap.

Calculate the minimum and maximum installed gaps across the complete battery tolerance stack. Then compare those dimensions with the compression-force-deflection curve of the selected MPP foam.

The nominal cell gap is only the starting point. Cell dimensional tolerance, module-frame tolerance, adhesive thickness and assembly variation can all change the real compression applied to the pad.

How Does Cell Swelling Affect MPP Foam Thickness?

If the MPP foam reaches its high-force region too early as the cell expands, stack pressure can rise beyond the intended mechanical design window.

Select the initial foam thickness so the pad remains within an acceptable compression range from beginning of life to end of life.

Battery compression-pad selection should therefore consider cell chemistry, expected swelling, available gap, beginning-of-life pressure and end-of-life pressure rather than thickness alone.^[1]

A thicker pad is not automatically safer. If the foam is too thick for the available gap, the battery module may begin life with excessive compression before cell swelling even occurs.

Should You Use a Fixed Compression Percentage?

Using a universal rule such as “compress every battery foam by 30%” can produce completely different forces when the MPP density, cell structure or material grade changes.

Use the actual compression-force-deflection data for the specific MPP foam grade. Compression percentage becomes meaningful only when it is connected to the required force or pressure range.

ASTM D3575 provides standardized test methods for flexible cellular materials made from olefin polymers. However, the measured results apply to defined test conditions and should not automatically be treated as exact battery-pack service performance.^[2]

Do not approve MPP foam thickness from a generic compression percentage alone. Temperature, aging time and repeated compression can change the mechanical response.

What Should Be Tested Before Final Thickness Approval?

An MPP foam thickness that works perfectly in CAD can still fail after thermal aging, repeated compression or installation into the actual battery module.

Test prototype pads at the minimum, nominal and maximum expected stack conditions. Include the real adhesive and laminated construction whenever possible.

Important validation points include initial compression force, compression set, stress relaxation, recovery, temperature aging and dimensional stability.

If adhesive is added to one or both sides, its thickness must also be included in the finished stack-up calculation. A 2 mm foam with adhesive and protective films is not necessarily a 2 mm finished component.

Not Sure Whether You Need 1 mm, 2 mm or 3 mm MPP Foam?

Send Fuqiang the minimum and maximum cell gap, expected cell swelling, target compression force, operating temperature and desired pad dimensions. Our engineering team can review candidate MPP thicknesses and prepare die-cut samples for compression and assembly validation.

FAQ

What is the best MPP foam thickness for EV batteries?

There is no universal best thickness. The correct MPP foam thickness depends on the battery gap, dimensional tolerance, cell swelling, foam compression curve and required pressure range.

Should MPP foam thickness equal the battery cell gap?

No. The pad normally needs to operate under controlled compression, so matching the uncompressed foam thickness directly to the nominal gap may not produce the required pressure.

Does thicker MPP foam provide better cushioning?

Not automatically. Increasing thickness changes the compression ratio and force applied to the cells. The result must remain within the battery manufacturer's acceptable pressure window.

How much should MPP foam be compressed?

There is no universal compression percentage. Use compression-force-deflection data from the specific MPP grade and compare it with the required cell pressure.

Does adhesive thickness count when selecting battery foam?

Yes. Pressure-sensitive adhesive, carrier films and laminated layers contribute to the finished stack thickness and should be included in tolerance calculations.

Should cell swelling be included when selecting foam thickness?

Yes. Expected cell swelling is one of the most important inputs because it changes pad compression and stack pressure throughout battery service life.

A 15-Year Automotive Wire Harness and Battery Materials Perspective

After 15 years working with automotive electrical components and battery materials, I recommend freezing MPP foam thickness only after reviewing the complete mechanical tolerance and compression window. The correct pad is not simply the one that fills the CAD gap on day one—it is the one that maintains controlled pressure as the battery changes throughout its service life.

Authoritative References

[1] Saint-Gobain — EV Battery Cell Swelling and Compression Management

[2] ASTM D3575-20 — Test Methods for Flexible Cellular Materials Made From Olefin Polymers

[3] ASTM D4819 — Standard Specification for Flexible Cellular Polyolefin Materials
